Live tooling (10,000 rpm)
C-axis
Programmable tailstock
Automatic tool presetter
Chip conveyor
Keyway broaching
High pressure coolant
Live tooling accessories
| Machining Length | 20.2" | 513.08 mm |
| Max Turning Dia | 15.1" | 383.54 mm |
| # Axis | 4 | 4 |
| Chuck Size | 6" | 152.4 mm |
| Bar Capacity | 2" | 50.8 mm |
| Power | 20 hp | 14.9 kW |
| Power (Live Tooling) | 7.5 hp | 5.6 kW |
| Max RPM | 6,000 RPM | 6,000 RPM |
| Max RPM (Live Tooling) | 10,000 RPM | 10,000 RPM |
| Turning Dia | 15.2" | 386.08 mm |
| X-Axis Travel | 10.2" | 259.08 mm |
| Z-Axis Travel | 23.2" | 589.28 mm |
| Tailstock | Yes | Yes |
| Quill Dia | 3.1" | 78.74 mm |
| Tailstock Travel | 22.2" | 563.88 mm |
| Tailstock Taper | MT4 | MT4 |
| Live Tooling | Yes | Yes |
| Sub Spindle | No | No |
| Rapid Traverse (X/Z) | 1,181 in/min. | 1,181 in/min. |
| Turret Capacity | 12 | 12 |
| Control | CNC (Celos) | CNC (Celos) |
| Dimensions | 111" X 81.9" X 84.4" | 111" X 81.9" X 84.4" |
| Weight | 10,780 lb | 10,780 lb |
**Under 50 hours!
