4th axis rotary table
Quick-turn 2-pallet changer
Heat expansion compensation
Chip conveyor
| X-axis | 21.7" | 551.18 mm |
| Y-axis | 15.7" | 398.78 mm |
| Z-axis | 16.3" | 414.02 mm |
| Pallet 1-L | 23.6" | 599.44 mm |
| Pallet 1-W | 16.7" | 424.18 mm |
| Max Table Load | 441 lb | 200 kg |
| RPM | 16,000 RPM | 16,000 RPM |
| RPM (Tapping) | 8,000 RPM | 8,000 RPM |
| Taper | 7/24 #30 | 7/24 #30 |
| Power | 13.5 hp | 10.1 kW |
| # ATC | 26 | 26 |
| Rapid Traverse (X/Y/Z) | 2,756 in/min. | 2,756 in/min. |
| Made In | Japan | Japan |
| Control | CNC (Brother CNC-B00) | CNC (Brother CNC-B00) |
| Dimensions | 122.7" X 74.4" X 110" | 122.7" X 74.4" X 110" |
| Weight | 9,920 lb | 9,920 lb |
