5-axis
Through spindle coolant
(3) rotary chucks
Automatic infeed unit designed for custom profile
Tool measuring probe
Infeed conveyor system to load custom profiles
Ambient coolant control
| X-Axis | 60" | 1,524 mm |
| Y-Axis | 17" | 431.8 mm |
| Z-Axis | 10" | 254 mm |
| U1 / U2 | 35" | 35" |
| A1/A2/A3 (Rotary Chuck) | ±190° | ±190° |
| Rotary Chucks | 3 | 3 |
| Max Part (Bar) | 5" X 5" | 5" X 5" |
| Max Part (Extrusion) | 6" X 10" | 6" X 10" |
| # Axis | 5 | 5 |
| Power | 60 hp | 44.7 kW |
| RPM | 30,000 RPM | 30,000 RPM |
| # ATC | 55 | 55 |
| Taper | HSK-63A | HSK-63A |
| Feedrate (X / Y / Z / U) | 2,400 in/min. | 2,400 in/min. |
| Made In | Sweden | Sweden |
| Control | CNC (Fanuc) | CNC (Fanuc) |
| Dimensions | 177.16" X 98.42" X 96" | 177.16" X 98.42" X 96" |
| Weight | 11,700 lb | 11,700 lb |
This equipment has been sold. Similar equipment available now is shown below.
