Coolant system
Fanuc servo drive motors
LAMOINE RTM programming system
Automatic lubrication system
Chip conveyor
| X-Axis | 126" | 3,200.4 mm |
| Y-Axis | 55.16" | 1,401.1 mm |
| Z-Axis | 35.46" | 900.68 mm |
| Power | 25 hp | 18.6 kW |
| RPM | 6,000 RPM | 6,000 RPM |
| Taper | BT-50 | BT-50 |
| Table-W | 47.28" | 1,200.9 mm |
| Table-L | 118.2" | 3,002.3 mm |
| Distance Between Columns | 63.04" | 1,601.2 mm |
| Distance Table Top To Spindle Nose | 34.27" | 870.46 mm |
| Max Table Load | 17,600 lb | 7,983.2 kg |
| Made In | Taiwan | Taiwan |
| Control | CNC (Fanuc O-M) | CNC (Fanuc O-M) |
This equipment has been sold. Similar equipment available now is shown below.
