Full 5-axis
Through spindle coolant (213 psi)
Palletech 6-pallet changer
Renishaw RMP600 touch probe
Renishaw NC4 laser tool setter
Air blast for NC4
Chip conveyor
| X-Axis | 24.8" | 629.92 mm |
| Y-Axis | 30.12" | 765.05 mm |
| Z-Axis | 20.08" | 510.03 mm |
| A-Axis | -120° ~ +30° | -120° ~ +30° |
| C-Axis | 360° | 360° |
| Power | 30 hp | 22.4 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 120 | 120 |
| Taper | CAT-40 | CAT-40 |
| Table-W | 19.69" | 500.13 mm |
| Table-L | 19.69" | 500.13 mm |
| Distance Spindle Nose To Table Top | 29.13" | 739.9 mm |
| # Axis | 5 | 5 |
| Max Table Load | 1,102 lb | 1,102 lb |
| Max Workpiece Height | 19.69" | 500.13 mm |
| Max Worpiece Diamenter | 28.74" | 730 mm |
| Rapid Traverse (X/Y/Z) | 1,574 in/min. | 1,574 in/min. |
| Made In | Japan | Japan |
| Control | CNC (MAZATROL MATRIX) | CNC (MAZATROL MATRIX) |
| Dimensions | 308.5" X 254.74" X 171.25" | 308.5" X 254.74" X 171.25" |
| Weight | 37,500 lb | 37,500 lb |
*New spindle last year!
