Tailstock
Auxiliary high-pressure coolant pump
18" air chuck (front)
18" manual scroll chuck (rear)
(2) steady rest
(2) face groove holders
(1) set of hard jaws
(7) centers
Additional soft jaws
Chip conveyor
Multiple I.D. & O.D. tool holders
| Max Turning Dia | 13.8" | 350.52 mm |
| # Axis | 2 | 2 |
| Chuck Size | 18" | 457.2 mm |
| Spindle Through Hole | 4.13" | 104.9 mm |
| Power | 40 hp | 29.8 kW |
| Max RPM | 2,000 RPM | 2,000 RPM |
| Spindle Nose | A2-8 | A2-8 |
| X-Axis Travel | 9.3" | 236.22 mm |
| Z-Axis Travel | 116" | 2,946.4 mm |
| Tailstock | Yes | Yes |
| Quill Dia | 5.9" | 149.86 mm |
| Quill Travel | 3.94" | 100.08 mm |
| Tailstock Travel | 115.4" | 2,931.2 mm |
| Tailstock Taper | MT5 | MT5 |
| Live Tooling | No | No |
| Sub Spindle | No | No |
| Rapid Traverse (X/Z) | 189 / 378 in/min. | 189 / 378 in/min. |
| Turret Capacity | 8 | 8 |
| Control | CNC (Fanuc MF-T6) | CNC (Fanuc MF-T6) |
| Dimensions | 227.16" X 73.22" X 67.95" | 227.16" X 73.22" X 67.95" |
| Weight | 19,841 lb | 19,841 lb |
*Air chuck requires new seals as it looses air presser after approx 45 min.
**Tailstock bearing needs replacement
