High-pressure through spindle coolant
Domange micro-filtration system
Siemens TSR touch probe
Blum laser tool checker
Spindle chiller
Chip conveyor
| X-Axis | 129.92" | 3,300 mm |
| Y-Axis | 90.55" | 2,300 mm |
| Z-Axis | 39.37" | 1,000 mm |
| B-Axis | ± 95° | ± 95° |
| C-Axis | ± 190° | ± 190° |
| Power | 40 hp | 29.8 kW |
| RPM | 18,000 RPM | 18,000 RPM |
| # ATC | 40 | 40 |
| Taper | HSK 63A | HSK 63A |
| Table-W | 49.21" | 1,249.9 mm |
| Table-L | 98.42" | 2,499.9 mm |
| Max Table Load | 19,800 lb | 8,981.1 kg |
| Rapid Traverse (X/Y/Z) | 984 / 1,574 / 1,574 in/min. | 984 / 1,574 / 1,574 in/min. |
| Made In | France | France |
| Control | CNC (Siemens Sinumerik 840 D) | CNC (Siemens Sinumerik 840 D) |
| Dimensions | 420.86" X 314.96" X 212.99" | 420.86" X 314.96" X 212.99" |
| Weight | 88,184 lb | 88,184 lb |
Includes unused rebuilt spare spindle
This equipment has been sold. Similar equipment available now is shown below.
