Twin-spindle (synchronized control)
Twin turret
Live tooling (5000 rpm)
Y-axis
C-axis
Spindle oil cooling
Chip conveyor
| Turning Dia | 9.1" | 231.14 mm |
| Max Swing Over Carriage | 11.4" | 289.56 mm |
| Machining Length | 26.5" | 673.1 mm |
| # Axis | 7 | 7 |
| Chuck Size | 8" | 203.2 mm |
| Bar Capacity (Main) | 2.6" | 66.04 mm |
| Bar Capacity (Sub) | 2.6" | 66.04 mm |
| Spindle Bore (Main) | 3" | 76.2 mm |
| Spindle Bore (Sub) | 3" | 76.2 mm |
| Power (Main) | 30 hp | 22.4 kW |
| Power (Sub) | 30 hp | 22.4 kW |
| Power (Milling Tool) | 7.4 hp | 5.5 kW |
| Max RPM (Main) | 5,000 RPM | 5,000 RPM |
| Max RPM (Sub) | 5,000 RPM | 5,000 RPM |
| Max RPM (Live Tooling) | 5,000 RPM | 5,000 RPM |
| X1/X2/X3-Axis Travel | 6.5″ / 7.7″ | 6.5″ / 7.7″ |
| Y-Axis Travel | ± 3.9" | ± 3.9" |
| C-Axis Rotation | 0.001Ëš | 0.001Ëš |
| Z1/Z2/Z3-Axis Travel | 27.6″ / 28.3" | 27.6″ / 28.3" |
| ZB-Axis Travel | 26.3" | 668.02 mm |
| Spindle Nose (Main) | A2-6 | A2-6 |
| Spindle Nose (Sub) | A2-6 | A2-6 |
| Tailstock | No | No |
| Live Tooling | Yes | Yes |
| Sub Spindle | Yes | Yes |
| Rapid Traverse (X1/X2) | 787 / 787 in/min. | 787 / 787 in/min. |
| Rapid Traverse (Z1/Z2) | 1,575 / 1,575 in/min. | 1,575 / 1,575 in/min. |
| Rapid Traverse (Y) | 295 in/min. | 7.5 m/min. |
| Rapid Traverse (ZB) | 1,575 in/min. | 40 m/min. |
| Turret Capacity (Upper) | 12 | 12 |
| Turret Capacity (Lower) | 12 | 12 |
| Control | CNC (Fanuc 31i-B) | CNC (Fanuc 31i-B) |
| Dimensions | 123.9" X 78.7" X 82.2" | 123.9" X 78.7" X 82.2" |
| Weight | 18.739 lb | 18.739 lb |
This equipment has been sold. Similar equipment available now is shown below.
