Sub-Spindle
Rotary tool
Cross-drilling
High-pressure coolant
Bar feeder
Chiller
Fire suppression system
Additional tooling
| Spindle Hole Dia | 0.787" | 19.99 mm |
| Max Machining Length | 3.149" | 79.985 mm |
| Max Drilling Dia (Main) | 0.393" | 9.9822 mm |
| Max Tapping Dia (Main) | M8 | M8 |
| Max Chucking Dia (Sub) | 0.787" | 19.99 mm |
| Max Drilling Dia (Sub) | 0.393" | 9.9822 mm |
| Max Tapping Dia (Sub) | M8 | M8 |
| Max Cross Drilling Dia | 0.314" | 7.9756 mm |
| Max Cross Tapping Dia | M6 | M6 |
| Max Drilling (Rotary) | 0.314" | 7.9756 mm |
| Max Tapping (Rotary) | M8 | M8 |
| Power (Main) | 5 hp | 3.7 kW |
| Power (Sub) | 5 hp | 3.7 kW |
| Power (Rotary Tool) | 2 hp | 1.5 kW |
| # Axis | 8 | 8 |
| RPM (Main) | 10,000 RPM | 10,000 RPM |
| RPM (Sub) | 12,000 RPM | 12,000 RPM |
| RPM (Rotary Tool) | 8,000 RPM | 8,000 RPM |
| RPM (Driven FR) | 8,000 RPM | 8,000 RPM |
| Turret Capacity | 12 | 12 |
| Front Tool Post | 7 Tools | 7 Tools |
| Rear Tool Post | 4 Tools | 4 Tools |
| Made In | Japan | Japan |
| Control | CNC (Fanuc 31i-B) | CNC (Fanuc 31i-B) |
| Dimensions | 119.68" X 62.4" X | 119.68" X 62.4" X |
| Weight | 9,920 lb | 9,920 lb |
*Only 8315 cutting hours
