Hydraulic tailstock
Multi-stage coolant pump (65 psi)
Programmable part catcher
Hydraulic chuck actuator
Tool presetter
Tool load monitoring system
Rigid tapping
| Swing | 23.6" | 599.44 mm |
| Swing Over Carriage | 15.7" | 398.78 mm |
| Machining Length | 21.6" | 548.64 mm |
| Max Turning Dia | 13.78" | 350.01 mm |
| # Axis | 2 | 2 |
| Chuck Size | 8.26" | 209.8 mm |
| Bar Capacity | 2.64" | 67.056 mm |
| Spindle Bore | 2.99" | 7.6 cm |
| Power | 20 hp | 14.9 kW |
| Max RPM | 4,500 RPM | 4,500 RPM |
| Spindle Nose | A2-6 | A2-6 |
| X-Axis Travel | 8.07" | 204.98 mm |
| Z-Axis Travel | 20" | 508 mm |
| Tailstock | Yes | Yes |
| Quill Dia | 2.6" | 66.04 mm |
| Tailstock Travel | 14.1" | 358.14 mm |
| Tailstock Taper | MT#4 (Live) | MT#4 (Live) |
| Live Tooling | No | No |
| Sub Spindle | No | No |
| Rapid Traverse (X/Z) | 1,181 / 1,417 in/min. | 1,181 / 1,417 in/min. |
| Turret Capacity | 12 | 12 |
| Made In | Korea | Korea |
| Control | CNC (FANUC 0i-Plus) | CNC (FANUC 0i-Plus) |
| Dimensions | 101.2" X 62.8" X 66.7" | 101.2" X 62.8" X 66.7" |
| Weight | 7,495 lb | 7,495 lb |
*DOM Nov.2023, Like new!
