Through spindle coolant
Full 4th axis
Chip conveyor
| X-Axis | 22" | 558.8 mm |
| Y-Axis | 22" | 558.8 mm |
| Z-Axis | 24.8" | 629.92 mm |
| Power | 25 hp | 18.6 kW |
| RPM | 14,000 RPM | 14,000 RPM |
| # ATC | 60 | 60 |
| Taper | CAT-40 | CAT-40 |
| Pallet-W | 15.7" | 398.78 mm |
| Pallet-L | 15.7" | 398.78 mm |
| Max Workpiece Swing | 24.8" | 629.92 mm |
| Max Workpiece Height | 35.4" | 899.16 mm |
| Max Pallet Load | 880 lb | 399.2 kg |
| Spindle To Pallet Surface | 25.1" | 637.54 mm |
| Pallet Center To Spindle Gage Plane | 28.7" | 728.98 mm |
| # Axis | 4 | 4 |
| Rapid Traverse (X/Y/Z) | 1,968 in/min. | 1,968 in/min. |
| Made In | Japan | Japan |
| Control | CNC (Fanuc MSX-501 III) | CNC (Fanuc MSX-501 III) |
| Dimensions | 288" X 96" X 108" | 288" X 96" X 108" |
| Weight | 21,384 lb | 21,384 lb |
B-axis needs to be replaced
