Live tooling (4 units 90Ā° āLā type, 3 units straight type)
C-axis
Hainbuch Spanntop Nova 65 collet chuck w/ hydraulic brake (main)
Seoma 8ā 3-jaw power chuck w/ hydraulic brake (sub)
Workpiece unloader
Workpiece conveyor
Chip conveyor
| Max Swing | 34.6" | 878.84 mm |
| Turning Dia | 14.96" | 379.98 mm |
| Machining Length | 20.47" | 519.94 mm |
| # Axis | 7 | 7 |
| Chuck Size | 8" | 203.2 mm |
| Through Spindle Hole (Main) | 2.55" | 64.77 mm |
| Through Spindle Hole (Sub) | 2.55" | 64.77 mm |
| Power (Main) | 20 hp | 14.9 kW |
| Power (Sub) | 20 hp | 14.9 kW |
| Max RPM (Main) | 5,000 RPM | 5,000 RPM |
| Max RPM (Sub) | 5,000 RPM | 5,000 RPM |
| Max RPM (Live Tooling) | 6,000 RPM | 6,000 RPM |
| X1/X2-Axis Travel | 9.64" | 244.86 mm |
| C-Axis Rotation | 0.001Ā° | 0.001Ā° |
| Z1/Z2-Axis Travel | 20.47" | 519.94 mm |
| Tailstock | No | No |
| Live Tooling | Yes | Yes |
| Sub Spindle | Yes | Yes |
| Turret Capacity (Upper) | 12 | 12 |
| Turret Capacity (Lower) | 12 | 12 |
| Control | CNC (FANUC OI-TD) | CNC (FANUC OI-TD) |
| Dimensions | 129ā X 86ā X 83ā | 129ā X 86ā X 83ā |
| Weight | 19,841 lb | 19,841 lb |
This equipment has been sold. Similar equipment available now is shown below.
