Full 4th axis
Through spindle coolant
ChipBLASTER high-pressure coolant pump (1000 psi)
Automatic pallet changer
Chip conveyor
| X-Axis | 25.2" | 640.08 mm |
| Y-Axis | 24" | 609.6 mm |
| Z-Axis | 26.8" | 680.72 mm |
| B-Axis | 0.001° | 0.001° |
| Power | 30 hp | 22.4 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 80 | 80 |
| Taper | CAT-0 BIG PLUS DOUBLE CONTACT | CAT-0 BIG PLUS DOUBLE CONTACT |
| Pallet-W | 15.7" | 398.78 mm |
| Pallet-L | 15.7" | 398.78 mm |
| Max Workpiece Diameter | 29.5" | 749.3 mm |
| Max Workpiece Height | 39.4" | 1,000.8 mm |
| Max Pallet Load | 1,100 lb | 499 kg |
| Spindle To Pallet Center | 30.7" | 779.78 mm |
| # Axis | 4 | 4 |
| Rapid Traverse (X/Y/Z) | 2,362 in/min. | 2,362 in/min. |
| Made In | Taiwan | Taiwan |
| Control | CNC (FANUC 31i-MODEL A) | CNC (FANUC 31i-MODEL A) |
| Dimensions | 185” X 105” X 110” | 185” X 105” X 110” |
| Weight | 26,000 lb | 26,000 lb |
***7 units available
This equipment has been sold. Similar equipment available now is shown below.
