Full 4th axis
Through spindle coolant
ChipBLASER JV40 variable pressure coolant pump (1000 psi)
Chip Blaster coolant chiller
BIG-PLUS CAT-40
Renishaw RMP600-40 probe kit for CAT-40B+
Aeroex 1050 mist collector
Renishaw NC4 non-contact tool setter
Viewport installed on operator window
Dynamic fixture offset
| X-Axis | 28.7" | 728.98 mm |
| Y-Axis | 28.7" | 728.98 mm |
| Z-Axis | 34.6" | 878.84 mm |
| B-Axis | 360° | 360° |
| Power | 40 hp | 29.8 kW |
| RPM | 15,000 RPM | 15,000 RPM |
| # ATC | 60 | 60 |
| Taper | BIGPLUS CAT-40 | BIGPLUS CAT-40 |
| Pallet-W | 19.7" | 500.38 mm |
| Pallet-L | 19.7" | 500.38 mm |
| Max Workpiece Diameter | 31.5" | 800.1 mm |
| Max Workpiece Height | 39.4" | 1,000.8 mm |
| Spindle To Pallet Center | 38.6" | 980.44 mm |
| Spindle To Pallet Surface | 31.9" | 810.26 mm |
| # Axis | 4 | 4 |
| Rapid Traverse (X/Y/Z) | 2,362 in/min. | 2,362 in/min. |
| Made In | Korea | Korea |
| Control | CNC (Fanuc 31i-Model B) | CNC (Fanuc 31i-Model B) |
| Dimensions | 214.6" X 105.5" X 113.4" | 214.6" X 105.5" X 113.4" |
| Weight | 25,353 lb | 25,353 lb |
**ONLY 1900 HOURS!
This equipment has been sold. Similar equipment available now is shown below.
