SHIBAURA MACHINE BP-150.R22 HORIZONTAL CNC BORING MACHINE

SHIBAURA MACHINE BP-150.R22 HORIZONTAL CNC BORING MACHINE

Have one to sell?
905-635-7530
sales@cncsurplus.com
ConditionNew
Have one to sell?

Overview

Type:
Horizontal Table Type Boring Mills
Manufacturer:
SHIBAURA MACHINE
Model:
BP-150.R22
Condition:
Build To Order
Status:
For Sale

Description

Shibaura Machine BP-150.R22 Horizontal CNC Boring Machine, TSC, B-Axis, Rotary Milling Function, Portable Handwheel, Spindle Cooling Unit

7.8" long-nose through spindle coolant
B-axis
Rotary milling function
Portable handwheel
Spindle cooling unit
High-speed spindle (8000 rpm) (option)
Automatic measuring RENISHAW probe & calibration block (option)
Automatic Tool setting RENISHAW RTS probe (option)

Spindle Size5.9"149.86 mm
X-Axis160"4,064 mm
Y-Axis120"3,048 mm
Z-Axis60"1,524 mm
W-Axis28"711.2 mm
Power50 hp37.3 kW
RPM2,500 RPM2,500 RPM
Table-W70.8"1,798.3 mm
Table-L86.6"2,199.6 mm
Max Table Load44,000 lb44,000 lb
ATC6060
Rapid Traverse (X/Y/Z/W)393 / 393 / 393 / 196.8 in/min.393 / 393 / 393 / 196.8 in/min.
Positioning0.0003"0.0076 mm
Repeatability0.0002"0.0041 mm
ControlCNC (TOSNUC 999)CNC (TOSNUC 999)
Dimensions402" X 300" X 233.5"402" X 300" X 233.5"
