2-axis orthogonal electrospindle head (4Wdp)
HR410 electric handwheel
Laser tool presetter
15" color monitor
Dual chip conveyors
500L coolant tank w/ 30L pump
| X-Axis | 157" | 3,987.8 mm |
| Y-Axis | 98" | 2,489.2 mm |
| Z-Axis | 59" | 1,498.6 mm |
| A-Axis | +110°/-110° | +110°/-110° |
| C-Axis | +362°/-362° | +362°/-362° |
| Power | 40 hp | 29.8 kW |
| RPM | 20,000 RPM | 20,000 RPM |
| # ATC | 32 | 32 |
| Taper | HSK A63 | HSK A63 |
| Table-W | 78" | 1,981.2 mm |
| Table-L | 118" | 2,997.2 mm |
| Distance Spindle To Table | 62" | 1,574.8 mm |
| Distance Between Columns | 137" | 3,479.8 mm |
| Max Table Load | 22,000 lb | 9,979 kg |
| Feed Rate (X/Y/Z) | 1,181 in/min. | 1,181 in/min. |
| Made In | Italy | Italy |
| Control | CNC (Heidenhain iTNC 530) | CNC (Heidenhain iTNC 530) |
| Weight | 83,600 lb | 83,600 lb |
This equipment has been sold. Similar equipment available now is shown below.
