Gear hobbing option
Multi-threading option
Y-axis
B-axis
Live tooling
High-speed tool spindle (20,000 rpm)
(2) 8" Kitagawa hollow chucks
Through spindle coolant (tooling spindle)
Robot loader/unloader
Chelos ERGOline touch
Chip conveyor
Renishaw touch sensor
Tool presetter
Workpiece ejector
| Turning Dia | 24" | 609.6 mm |
| Max Swing Over Cross Slide | 25.9" | 657.86 mm |
| # Axis | 9 | 9 |
| Chuck Size (Main) | 8" | 203.2 mm |
| Chuck Size (Sub) | 8" | 203.2 mm |
| Bar Capacity | 2.5" | 63.5 mm |
| Through Spindle Hole (Main) | 2.87" | 72.898 mm |
| Through Spindle Hole (Sub) | 2.87" | 72.898 mm |
| Power (Main) | 30 hp | 22.4 kW |
| Power (Sub) | 30 hp | 22.4 kW |
| Max RPM (Main) | 5,000 RPM | 5,000 RPM |
| Max RPM (Sub) | 5,000 RPM | 5,000 RPM |
| Max RPM (Milling Tool) | 12,000 RPM | 12,000 RPM |
| Max RPM (Tool Spindle) | 20,000 RPM | 20,000 RPM |
| X-Axis Travel | 19.5" | 495.3 mm |
| Y-Axis Travel | ±4.9" | ±4.9" |
| B-Axis Rotation | ±120° | ±120° |
| Z-Axis Travel | 61.4" | 1,559.6 mm |
| Tailstock | No | No |
| Live Tooling | Yes | Yes |
| Sub Spindle | Yes | Yes |
| Turret Capacity (Lower) | 12 | 12 |
| ATC Positions | 80 | 80 |
| Made In | Japan | Japan |
| Control | CNC (Fanuc 31iB5) | CNC (Fanuc 31iB5) |
| Dimensions | 226" X 210" X 105" | 226" X 210" X 105" |
Includes tooling package worth over 220K USD
(Total replacement cost approximately $1.2M USD)
