High-speed roller-cam trunnion table
Through spindle coolant (300 psi)
Auxiliary coolant filter system
Programmable coolant nozzle
Belt chip conveyor
High-speed machining w/look-ahead
Dynamic work offsets
Wireless intuitive probing System
Spindle orientation
Power-failure detection module
Rigid tapping
| X-Axis | 30" | 762 mm |
| Y-Axis | 20" | 508 mm |
| Z-Axis | 20" | 508 mm |
| B-Axis | +110Ëš~ -35Ëš | +110Ëš~ -35Ëš |
| C-Axis | 360Ëš | 360Ëš |
| # Axis | 5 | 5 |
| Power | 30 hp | 22.4 kW |
| RPM | 15,000 RPM | 15,000 RPM |
| # ATC | 40 | 40 |
| Table-W | 19.7" | 500.38 mm |
| Table-L | 24.8" | 629.92 mm |
| Max Table Load | 660 lb | 299.4 kg |
| Rapid Traverse | 1,200 in/min. | 30.5 m/min. |
| Made In | United States | United States |
| Control | CNC (HAAS) | CNC (HAAS) |
| Dimensions | 160" X 94" X 110" | 160" X 94" X 110" |
| Weight | 19,000 lb | 19,000 lb |
