Hydraulic tailstock
Hydraulic compound slide rest
Variable speed spindle (10-600 rpm)
2 compounds
| Height of Centers | 82.68" | 2,100.1 mm |
| Centers Height Upper Bed | 29.58" | 751.33 mm |
| Center Height Lower Bed | 43.31" | 1,100.1 mm |
| Upper Bed Adjustment | 39.37" | 1,000 mm |
| Longitudinal Adjustment | 39.37" | 1,000 mm |
| Traverse Motion | 11.81" | 299.97 mm |
| Top Slide Adjustment | 29.53" | 750.06 mm |
| Compound Slide Pivot Angle | 360° | 360° |
| Rapids (Long) | 98.4 in/min. | 2.5 m/min. |
| Power | 17 hp | 12.7 kW |
| Max RPM | 600 RPM | 600 RPM |
| Made In | Germany | Germany |
| Dimensions | 20' X 11' X 75" | 20' X 11' X 75" |
| Weight | 35,200 lb | 35,200 lb |
This equipment has been sold. Similar equipment available now is shown below.
