TAILSTOCK
DEEP BORING BAR CUSTOM MADE BLOCK ATTACHMENT
DUAL 25" 3-JAW CHUCK
FRONT CHUCK HAS MULTIPLE JAW LOCATIONS
STEADY REST (2)
TOOL HOLDER AND BAR HOLDER
| Swing | 30" | 762 mm |
| Bed Width | 22" | 558.8 mm |
| Bed Length | 160" | 4,064 mm |
| Centers | 126" | 3,200.4 mm |
| Max Cutting Dia | 18" | 457.2 mm |
| Chuck Size | 25" | 635 mm |
| Spindle Bore | 10.05" | 255.27 mm |
| Power | 50 hp | 37.3 kW |
| RPM | 800 RPM | 800 RPM |
| Turret Stations | 12 | 12 |
| X-Axis Travel | 17.9" | 454.66 mm |
| Y-Axis Travel | 125" | 3,175 mm |
| Max Workpiece Weight (With Tailstock) | 6600 LBS | 6600 LBS |
| Rapid Traverse (X/Z) | 390 / 470 IPM | 390 / 470 IPM |
| Spindle Nose | A2-15 | A2-15 |
| Quill Stroke | 9" | 228.6 mm |
| Quill Dia | 5" | 127 mm |
| Control | CNC (Fagor) | CNC (Fagor) |
| Dimensions | 232” x 103” x 88” | 232” x 103” x 88” |
| Weight | 24000 LBS | 24000 LBS |
FRONT CHUCK IS OFF AND THE PINIONS NEED TO BE REPAIRED. UNIT IS IN GOOD WORKING CONDITION OTHERWISE.
This equipment has been sold. Similar equipment available now is shown below.
