31.5" 4 jaw chuck (5" hole)
12.4" steady rest
19.7" steady rest
3-phase AC servo drives
Chip conveyor
Quick-change tool holder
Automatic feed
Manuals and documentation
| Swing | 39.37" | 1,000 mm |
| Swing Over Cross Slide | 25.5" | 647.7 mm |
| Machining Length | 118" | 2,997.2 mm |
| # Axis | 2 | 2 |
| Chuck Size | 31.5" | 800.1 mm |
| Bar Capacity | 5.5" | 139.7 mm |
| Max RPM | 1,600 RPM | 1,600 RPM |
| Tailstock | Yes | Yes |
| Quill Dia | 4.92" | 124.97 mm |
| Tailstock Travel | 11.02" | 279.91 mm |
| Tailstock Taper | MK6 | MK6 |
| Live Tooling | No | No |
| Sub Spindle | No | No |
| Made In | Germany | Germany |
| Control | CNC (Sinumerik 810 D) | CNC (Sinumerik 810 D) |
| Dimensions | 224" X 95" X 79" | 224" X 95" X 79" |
| Weight | 19,180 lb | 19,180 lb |
**Trouble homing sometimes and glass scale needs to be sprayed with cleaner to get it to work. Scale replacement needed.
